Specifications
Continued from previous page
RAID
Intel
®
Z270 Chipset
y Supports RAID 0, RAID1, RAID 5 and RAID 10 for SATA
storage devices
y Supports RAID 0 and RAID1 for M.2 PCIe storage devices*
* M.2 PCIe RAID volume can be created with M.2 GENIE. Please refer to page
41 for details about M.2 GENIE.
USB
y ASMedia
®
ASM2142 Chipset
 1x USB 3.1 Gen2 (SuperSpeed USB 10Gbps) Type-C port
on the back panel
 1x USB 3.1 Gen2 (SuperSpeed USB 10Gbps) Type-A port
on the back panel
y Intel
®
Z270 Chipset
 8x USB 3.1 Gen1 (SuperSpeed USB) ports (4 Type-A
ports on the back panel, 4 ports available through the
internal USB connectors)
 6x USB 2.0 (High-speed USB) ports (2 Type-A ports on
the back panel, 4 ports available through the internal
USB connectors)
Audio
y Realtek
®
ALC892 Codec
y 7.1-Channel High Definition Audio
y Supports S/PDIF output
LAN 1x Intel I219-V Gigabit LAN controller
Back Panel
Connectors
y 1x PS/2 keyboard/ mouse combo port
y 2x USB 2.0 Type-A ports
y 1x DVI-D port
y 1x USB 3.1 Gen2 Type-A port
y 1x USB 3.1 Gen2 Type-C port
y 4x USB 3.1 Gen1 Type-A ports
y 1x HDMI
™
port
y 1x LAN (RJ45) port
y 5x OFC audio jacks
y 1x Optical S/PDIF OUT connector
