Specifications
Specifications
CPU
Supports 7th/6th Gen Intel
®
Core
™
i3/i5/i7 processors,
and Intel
®
Pentium
®
and Celeron
®
processors for Socket
LGA1151
Chipset Intel
®
Z270 Chipset
Memory
y
4x DDR4 memory slots, support up to 64GB

7th Gen processors support DDR4 3800(OC)/ 3600(OC)/
3200(OC)/ 3000(OC)/ 2800(OC)/ 2600(OC)/ 2400/ 2133
MHz*

6th Gen processors support DDR4 3600(OC)/ 3200(OC)/
3000(OC)/ 2800(OC)/ 2600(OC)/ 2400(OC)/ 2133 MHz*
y
Dual channel memory architecture
y
Supports Intel
®
Extreme Memory Profile (XMP)
Expansion Slots
y 3x PCIe 3.0 x16 sl
ots (support x16/x4/x1 modes)
y 3x PCIe 3.0 x1 slots
* The PCI_E4 slot will be unavailable when an M.2 PCIe SSD module has been
installed in the M.2_2 slot.
** The PCI_E2/ PCI_E5 slot will be unavailable when an expansion card has
been installed in the PCI_E3/ PCI_E6 slot.
Onboard Graphics
y 1x HDMI™ port, supports a maximum resolution of
4096x2160@30Hz(7th CPU), 4096x2160@24Hz(6th CPU),
2560x1600@60Hz
y 1x DVI-D port, supports a maximum resolution of
1920x1200@60Hz
Multi-GPU y Supports 2-Way AMD
®
CrossFire
™
Technology
Storage
Intel
®
Z270 Chipset
y 6x SATA 6Gb/s ports*
y 2x M.2 slots (Key M)
 Support up to PCIe 3.0 x4 and SATA 6Gb/s
 Support PCIe 3.0 x4 NVMe U.2 SSD with Turbo U.2 Host
Card**
 M2_1 slot supports 2242/ 2260 /2280/ 22110 storage
devices
 M2_2 slot supports 2242/ 2260 /2280 storage devices
 Intel
®
Optane™ Memory Ready for all M.2
y Supports Intel
®
Smart Response Technology for Intel
Core
™
processors
* M.2 and SATA ports maximum support 2x M.2 PCIe SSDs + 6x SATA HDDs.
Please refer to page 30 for M.2 slots with examples of various combination
possibilities.
** The Turbo U.2 Host Card is not included, please purchase separately.
Continued on next page
