Spectrum for EMI reducton.
The greater the Spread Spectrum value s, the greater the EMI s reduced, and the
system wll become less stable. For the most sutable Spread Spectrum value, please
consult your local EMI regulaton.
Remember to dsable Spread Spectrum f you are overclockng because even a slght
jtter can ntroduce a temporary boost n clock speed whch may just cause your
overclocked processor to lock up.
Hybrd Dgtal Power
Press <Enter> to enter the sub-menu.
CPU Core Vdroop O󰘯set Control
Ths tem s used to select the CPU core Vdroop o󰘯set control mode.
GPU Vdroop O󰘯set Control
Ths tem s used to select the GPU Vdroop o󰘯set control mode.
Dgtal Compensaton Level
Ths tem s used to select the current compensaton speed when the MOS phases
be changed. For overclockng or full-loadng of system, t s recommended ths 󰘰eld
set to [hgh]. Please note that overclockng behavor and stablty s not guaranteed.
CPU Core OCP Expander
Ths tem s used to expand the lmtaton of CPU core OCP (Over Current Protec
-
ton). The hgher expandng value ndcates less CPU protecton. So please adjust
the CPU voltage carefully f needed.
GPU OCP Expander
Ths tem s used to expand the lmtaton of GPU OCP (Over Current Protecton).
The hgher
expandng value ndcates less GPU protecton. So please adjust the
GPU voltage carefully f needed.
CPU Core Swtchng Frequency
Ths tem allows you to spec󰘰c the CPU core swtchng frequency.
GPU Swtchng Frequency
Ths tem allows you to spec󰘰c the GPU swtchng frequency.
CPU Core Voltage/ CPU I/O Voltage/ DRAM Voltage/ GPU Voltage/ System Agent
Voltage (SA)/ CPU PLL Voltage/ DDR_VREF_CA_A/ DDR_VREF_CA_B/ DDR_VREF_
DA_A/ DDR_VREF_DA_B/ PCH 1.05
These tems are used to adjust the voltage of CPU, Memory, GPU and chpset.
Current CPU Core/ CPU I/O/ DRAM/ GPU Voltage
These tems show current CPU/ DRAM/ GPU voltage. Read-only.
Overclockng Pro󰘰les
Press <Enter> to enter the sub-menu.
Overclockng Pro󰘰le 1/ 2/ 3/ 4/ 5/ 6
Press <Enter> to enter the sub-menu.
Set Name for Overclockng Pro󰘰le 1/ 2/ 3/ 4/ 5/ 6
Gve a name by typng n ths tem.
•
•
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
