MSI Z77A

1-12
Gettng Started
Inspect the CPU to check f t s
properly seated n the socket. Press
the loadng lever down and lock t
under the retenton tab.
5. Evenly spread a thn layer of
thermal paste (or thermal tape) on
the top of the CPU. Ths wll help n
heat dsspaton and prevent CPU
overheatng.
6.
Locate the CPU fan connector on the
manboard.
7. Place the heatsnk on the manboard
wth the fan’s wres facng towards the
fan connector and the hooks matchng
the holes on the manboard.
8.
