AIR COMPRESSOR MANUAL
- 11 -
FOR 200Kg/㎠ METHOD FOR 300Kg/㎠
CONNECT
DISCHARGE
VALVE AND AIR
TANK
LOCK THE
DISCHARGE
CONNECTION HANDLE
(CW)
OPEN THE
DISCHARGE VALVE
AND
AIR TANK VALVE
(CCW)
6-3 Operating Procedures
Before filling operation is executed, check if:
￭ Tanks are suitable for final pressure.
￭ Hydro static test is done.
￭ The automatic switch-off, or safety valves must be checked
WARNING
Do not fill the pressure bottle from 200 bar to 300 bar.
Please drain all remain pressure in the machine down to 0 bar.
How To Connect The Injector And Tank
※The disjointing reverse order of assembly
To Next Page
