USER MANUAL MCL100 Pág.
6
Connecting the battery to the flasher
Quickly, easily and manually without the
need for a specific tool, the cables that
connect the battery to the flasher are
connected, according to the attached
image.
4.2.CLOSING THE LANTERNE
The lantern has a closing position to ensure watertightness, keep out water entry and protect
the internal components from external agents follow signs for closing it:
Check the position and connection of
elements:
Ensure that the position of the battery,
wiring and flasher is located as per the
attached picture, in order to ensure a
correct operation.
Place the back cover of the beacon:
Place the back cover facing it with the
fixing holes and with the valve on the side
where the battery is not located, pressing
to fit the flange into its position of sealing
and closure.
