MSM MCL100 - Technical Features

USER MANUAL MCL100 Pág.
3
Rv07
3. Technical features
Optical System
Light source:
Diodos LED, con lente acrílica de gran precisión.
Luminous range:
Up to 5 mn (T=0,74) 6 mn (T=0,85).
Colours available:
White, Green, red and amber.
Vertical divergence:
Up to 15º (50% lo).
Leds / level
1 leds
Levels
1
LED average life:
More tan 100,000 hours.
Módulos solares:
1 uds. de 1 W and 6V.
Battery:
6V 4.8Ah Ah Lead Crystal® maintenance-free.
Autonomy without solar charging:
Up to 250 hours.
Electronic control
Flash rhythms:
256 (6 nos. User selectable).
Day/night threshold:
Adjustable in lux.
Solar charge regulation function:
Regulation in 3 phases.
Settings:
PC, Programmer IR
Modos de sincronización
Version with optional GPS. MCL100-SYNC
Energy management:
Dynamic, according to latitude.
Light intensity reduction due to low
battery:
Configurable by the user.
Materials and environment
Base:
Polyamide PA66-GF30.
Lens cover:
Acrylic, UV stabilised.
Inside hardware:
Stainless Steel.
Vibration resistance:
MIL-STD-202G, Method 204D (5G).
Shock resistance:
MIL-STD-202G, Method 213B.
Watertightness degree:
IP 68.
Fixings:
3-4 bolts in a 200mm diameter.
Humidity resistance:
100%. Pressure-compensation valve to avoid condensation.
Weight
1.5 Kg
Temperature range:
From -20º to 70ºC.
Packaging
30x30x30 cms 2 Kg
