10 Figures
v
Fig. 1 Fig. 3
PCB with Sensor Cartridge SC2 connection to PCB
Fig. 2
Calibration adapter C2Z4
X2
X3
X7
X4
94 mm
79 mm
Mounting
Mounting
Mounting
Mounting
115 mm
130 mm
180 mm
D = 4 mm
