OPERATING AND MAINTENANCE MANUAL
Chapter 3 - Technical data
TAEevo Tech MINI 02÷10
11
The data in this manual are not binding and they can be modified by the manufacturer without notice. Reproduction of this manual is strictly prohibited
EN
ENGLISH
CHAPTER 3
TECHNICAL DATA
The data plate affixed to the unit bears the following technical data:
ATTENTION
The performance of the unit depends mainly on the flow rate and temperature of water in the user circuit, and the
condenser thermal exchange fluid temperature. These values are defined at the time of the offer.
MODEL and CODE The model number and the code identify the size of the unit and the type of
construction.
MANUAL Code number of the manual.
SERIAL NUMBER Construction number of the unit.
MANUFACTURING YEAR Year of unit’s final testing.
VOLTAGE/PHASE/FREQUENCY Electrical power supply characteristics.
MAX CURRENT DRAW (I max) Unit current draw in limit operating conditions.
INSTALLED POWER (P max) Unit power input in limit operating conditions
PROTECTION RATING According to European standard EN 60529.
REFRIGERANT Refrigerant fluid in the unit.
REFRIGERANT QUANTITY Quantity of refrigerant fluid contained in the unit.
MAX REFRIG. PRESS. Refrigerant circuit design pressure
MAX. REFRIG. TEMP. Refrigerant circuit design temperature
USER CIRC. FLUID Type of user fluid utilised by the unit (normally water)
MAX WORKING PRESSURE Max. design pressure of the user circuit.
MAX. TEMPERATURE Maximum design temperature of the user circuit; this should not be confused
with the maximum working temperature which is established when the offer is
made.
CONDENSER COOLING FLUID Fluid used by the unit to cool the condenser (this data is not present if the unit is
air cooled condensed).
MAX WORKING PRESSURE Max. design pressure of the condenser cooling circuit (this data is not present if
the unit is air cooled condensed).
MAX. TEMPERATURE Condenser cooling circuit maximum design temperature (this information is not
given if the unit’s condenser is air-cooled).
SOUND PRESSURE LEVEL Free field sound pressure level in hemispherical radiation conditions (open
field) at a distance of 1 m from the condenser side of the unit and a height of 1.6
m from the ground.
AMBIENT TEMPERATURE Minimum and maximum values of ambient air temperature.
WEIGHT Approximate weight of the unit before packing.
