MTD Jet sweep blower - Attaching the Upper Handle

Assembly & Set-Up
3
6
NOTE: All references to the left or right side of the jet sweep
blower are from the operator’s position. Any exceptions will be
noted.
Assembly
Attaching the Upper Handle
1. Remove the carriage screws and star knobs from the upper
holes in the lower handle. See Fig. 3-1.
Figure 3-1
2. Place the upper over the lower handle, aligning the upper
holes/metal tabs in the upper handle with the upper holes/
lower holes in the lower handle. See Fig. 3-2.
Figure 3-2
3. Secure with the carriage screws and star knobs removed
earlier. See Fig. 3-2.
Contents of Crate
• One Jet Sweep Blower • One Upper Handle • One Chute Attachment
• One Jet Sweep Blower Operator’s
Manual
• One Engine Operator’s Manual
