Controls & Features
4
8
Jet Sweep Blower controls and features are illustrated in Fig 4-1
and described below.
WARNING! Read and follow all safety rules and
instructions in this manual, including the entire
Operation section, before attempting to operate
this machine. Failure to comply with all safety rules
and instructions may result in personal injury.
Engine
Refer to the Engine Operator’s Manual for details regarding all
engine-related controls and features.
Blower Direction Lever
The air flow can be directed to one
of three directions using the blower
direction lever to reposition the
louvers.
WARNING! Do not stand
in front of discharge area.
BLOWER DIRECTION LEVER
UP
AIR FLOW
DOWN
Discharge Chute
Blower Direction Lever
Blower Housing
Figure 4-1
