MTD P805K - Page 33

33
Model P805K
REF.
NO.
PART
NUMBER DESCRIPTION
1 710-0227 Screw, #8-18, 0.500
2 710-0451 Bolt, Carriage, 5/16-18, .750 Gr1
3 710-0599 Screw, /4-20, 0.500
4 710-0604A Screw, 5/16-18, 0.625
5 710-0788 Screw, 1/4-20, 1.000
6 710-0895 Screw, 1/4-15, 0.750
7 710-0932 Screw, Carriage, 1/4-20, 1.00, Gr1
8 712-0271 Nut, Sems, 1/4-20
9 712-04063 Nut, Flange Lock, 5/16-18, GrF, Nylon
10 725-1713 Switch, Spring
11 726-0320 Plate, Insulator Nut
12 731-1990 Cover, Lift Lever
13 731-1993A Cover, w/ Cup Holder
14 731-2480A Cover, Shift
15 731-2618 Fender Flare, RH
16 731-2619 Fender Flare, Fender, LH
17 736-0607 Washer, Lock, 5/16 Ext. Tooth
18 736-3078 Washer, Flat, .344 x 1.0 x .063
19 783-04331A Fender, 2-Speed
20 783-0677B Lift Bracket, Adjustment
21 783-1489B Seat Bracket
22 720-04061 Knob, 3/8-16, .875
23 732-1184 Spring, Extension, .80 Dia x 4.6 Lg.
24 738-0296 Shoulder Screw .437 x .286 Lg
25 738-04012A Shoulder Screw, .625 x .145, 3/8-16
26 783-04081A Pivot Bracket, Seat
27 783-0209D Bracket, Seat Lift
28 757-04003 Seat, High Back
29 726-3046 Clip, Ratchet, .250 Dia
30 735-0656 RH Foot Pad
31 735-0657 LH Foot Pad
32 710-0227 Screw, #8-18 x .50
33 726-0279 Plate, Insulator
34 725-1303 Spring Switch, Outer
35 725-1439 Spring Switch, Inner
36 726-0278 Plate, Insulator Boss
