MTD P805K - Page 34

34
REF.
NO.
PART
NUMBER DESCRIPTION
1 683-04118 Shaft Assembly, Lift
2 711-0332 Pin, Clevis, .50 Dia x .78 Lg
3 783-0720A Bracket, Deck
4 712-04065 Nut, Nylon Lock, 3/8-16
5 712-04063 Nut, Nylon Lock, 5/16-18, Gr5
6 712-3083 Nut, Hex Lock, 1/2-13, Gr8, Nylon
7 714-0104 Pin, Cotter, .072 Dia. x 1.13 Lg
8 714-0111 Pin, Cotter, 3/32, 1.0
9 714-04023 Pin, Click, .092 x 1.64 Lg
10 716-0106A E-ring, .625 Dia. Shaft
11 720-0311 Grip, Handle
12 732-0874 Spring, Torsion
18 738-0138A Screw, Hex Cap, 5/16-18x.620 Gr2
19 738-0143 Shoulder Screw, 3/8-16
20 741-0225
Bearing, Hex Flange
22 746-0968 Cable, Lift, 16.16 Lg
23 747-04155 Handle, Lift
24 747-1324 Rod, Deck .5" Dia.
25 756-1154 Pulley, Roller
26 783-0678A Arm, Lift
27 712-0206 Nut, Hex, 1/2-13
5
8
4
4
8
5
9
1
7
22
20
25
11
18
26
23
18
14
10
12
25
22
20
10
26
19
24
2
9
6
A
A
3
26
27
19
Model
P805K
