7.21.6 ECU 7 engine governor – Removal and installation
Preconditions
☑ Engine is stopped and starting disabled.
CAUTION
Wrong engine governor installed.
Engine damage!
• When reassembling an engine, make sure that the governor with the data record for the given
engine is installed.
Removing engine governor from
engine
1. Note or mark assignment of cables and
connectors.
2. Remove all screws (2).
3. Undo latches (3) of the connectors.
4. Remove all connectors.
5. Remove screws (1).
6. Take off engine governor.
Installing engine governor on engine
1. Install in reverse order. In doing so, ensure correct assignment of connectors and sockets.
2. Check rubber mount before installation.
Result: If the rubber mount is porous or defective, replace it.
M015650/03E 2011-10 | Task Description | 137
TIM-ID: 0000000049 - 005
