Engine, right side
Item Description Monitoring of
1 YB33 Fuel temperature
2 B48 Fuel pressure (in rail)
3 B16 (option) Coolant pressure
4 F46 Leak fuel level
5 Y27.2 4-2-directional control valve, B-side
6 B4.22 Exhaust temperature, B-side
7 F41 2-2-directional control valve
M015650/03E 2011-10 | General Information | 29
TIM-ID: 0000008412 - 003
