MTU 16V2000S56 - Page 22

Number of cylinders 12
16
Lube oil operating pressure before engine, warning R bar 6.4 7.0
Lube oil operating pressure before engine, shutdown L bar 5,9 6.5
FUEL SYSTEM
Number of cylinders 12
16
Fuel pressure at engine inlet connection, min. (when engine is
starting)
L bar -0.5 -0.5
Fuel pressure at engine inlet connection, min. (when engine is run-
ning),
L bar -0.5 -0.5
Fuel pressure at engine inlet connection, max. (when engine is
starting)
L bar 0.5 0.5
GENERAL OPERATING DATA
Number of cylinders 12
16
Coolant preheating: preheating temperature (min.) L °C 32 32
INCLINATIONS, STANDARD OIL SYSTEM (reference: waterline)
Number of cylinders 12
16
Longitudinal inclination, continuous max. driving end down (Op-
tion: max. operating inclinations)
L Degrees
(°)
15 10
Longitudinal inclination, continuous max. driving end up (Option:
max. operating inclinations)
L Degrees
(°)
15 10
Transverse inclination, continuous max. (option: max. operating in-
clinations)
L Degrees
(°)
15 10
CAPACITIES
Number of cylinders 12
16
Engine coolant capacity, engine side (without cooling equipment) R Liters 63 83
Charge-air coolant, engine side R Liters 25 37
Total engine oil capacity at initial filling (standard oil system) (Op-
tion: max. operating inclinations)
R Liters 103 158,5
Oil pan capacity at dipstick mark “min.” (standard oil system) (Op-
tion: max. operating inclinations)
L Liters 73 107
Oil pan capacity at dipstick mark “max.” (standard oil system) (Op-
tion: max. operating inclinations)
L Liters 81 120
ACOUSTICS
Number of cylinders 12
16
Exhaust noise, unsilenced - BL (free-field sound pressure level Lp,
1 m distance, ISO 6798, +3 dB(A) tolerance)
R dB(A) 103 109
Exhaust noise, unsilenced - BL (sound power level LW, ISO
6798+3 dB(A) tolerance)
R dB(A) 116 122
22 | Product Summary | MS150094/02E 2015-05
TIM-ID: 0000024846 - 003
