6.4.2 Injector – Removal and installation
Preconditions
☑ Engine is stopped and starting disabled.
Special tools, Material, Spare parts
Designation / Use Part No. Qty.
Installation device
F6790085 1
Puller
F6790636 1
Fuel suction device
F30378207 1
Torque wrench, 1–5 Nm
F30452774 1
Torque wrench, 20–100 Nm
F30026582 1
Ratchet
F30027340 1
Adapter
F30006234 1
Adapter
F30452771 1
Socket wrench, 19 mm
F30453236 1
Crowfoot wrench, 19 mm
F30027424 1
Crowfoot wrench, 22 mm
F30027425 1
Double-head box wrench
F30011450 1
Socket wrench, 24 mm
F30453238 1
Assembly compound (Hakuform 30–15)
X00067260 1
Engine oil
Sealing ring
(→ Spare Parts Catalog)
WARNING
Fuels are combustible and explosive.
Risk of fire and explosion!
• Avoid open flames, electrical sparks and ignition sources.
• Do not smoke.
• Wear protective clothing, protective gloves, and safety glasses / facial protection.
WARNING
Compressed air gun ejects a jet of pressurized air.
Risk of injury to eyes and damage to hearing, risk of rupturing internal organs!
• Never direct air jet at people.
• Always wear safety goggles/face mask and ear defenders.
Preparatory steps
1. Shut off fuel supply line.
2. Drain fuel (→ Page 90).
3. Remove cylinder head cover (→ Page 80).
82 | Task Description |
MS150094/02E 2015-05
TIM-ID: 0000023980 - 004
