GENERAL OPERATING DATA
Number of cylinders 12
16
Cold start capability: air temperature (w/o start aid, w/o preheat-
ing) - (case A)
R °C 0 0
Firing speed, from R rpm 100 100
Firing speed, to R rpm 120 120
INCLINATIONS, STANDARD OIL SYSTEM (reference: waterline)
Number of cylinders 12
16
Longitudinal inclination, continuous max. driving end down (Op-
tion: max. operating inclinations)
L Degrees
(°)
10 10
Longitudinal inclination, continuous max. driving end up (Option:
max. operating inclinations)
L Degrees
(°)
10 10
Transverse inclination, continuous max. (option: max. operating in-
clinations)
L Degrees
(°)
10 10
CAPACITIES
Number of cylinders 12
16
Engine coolant capacity, engine side (without cooling equipment) R Liters
Charge-air coolant, engine side R Liters
Total engine oil capacity at initial filling (standard oil system) (Op-
tion: max. operating inclinations)
R Liters 111
Oil change quantity, max. (standard oil system) (Option: max. op-
erating inclinations)
R Liters 94 125
Oil pan capacity at dipstick mark “min.” (standard oil system) (Op-
tion: max. operating inclinations)
L Liters (86)
Oil pan capacity at dipstick mark “max.” (standard oil system) (Op-
tion: max. operating inclinations)
L Liters (94)
WEIGHTS / MAIN DIMENSIONS
Number of cylinders 12
16
Engine weight, dry (basic engine configuration acc. to scope of de-
livery specification)
R kg 3005 3350
ACOUSTICS
Number of cylinders 12
16
Exhaust noise, unsilenced - BL (free-field sound pressure level Lp,
1m distance, ISO 6798, +3dB(A) tolerance)
R dB(A) 107 108
Exhaust noise, unsilenced - BL (sound power level LW, ISO
6798+3 db(A) tolerance)
R dB(A) 120 121
Engine surface noise with attenuated intake noise (filter) - BL
(free-field sound power level Lp, 1 m distance, ISO 6798, +2dB(A)
tolerance)
R dB(A) 103 104
Engine surface noise with attenuated intake noise (filter) - BL
(sound power level LW, ISO 6798+2dB(A) tolerance)
R dB(A) 121 122
MS150094/02E 2015-05 | Product Summary | 33
TIM-ID: 0000025538 - 002
