2. Open threaded vent plug (5) of contaminated
filter.
3. Unlock drain valve (6) by pressing toggle and
open it.
4. Drain water and contamination from filter.
5. Close drain valve (6).
6. Remove screws securing the cover and take
off cover (2).
7. Remove spring housing (4) and filter ele-
ment (3).
8. Insert new filter element (3) and spring hous-
ing (4).
9. Fill filter housing with clean fuel.
10. Place new gasket in cover (2).
11. Fit cover with gasket and secure it with
screws.
12. Cut in the cut-out filter again.
13. Close threaded vent plug (5) when fuel
emerges.
14. Set adjustable pointer of differential pressure
display instrument (→ Page 103).
