MTX Road thunder - Power Connection; B+(12 V) Connection; Remote Connection; GND Connection

MAX BASS CONTROL
POWER
WIDE
SWEEP
MIN
MAX
MIN
MAX
35Hz
50Hz
80Hz
BALANCED
INPUT
DASH
REMOTE
OUTPUT
+12V - REM - GND
L R L R
DIGITAL BASS PROCESSOR
Remote Control
RTLDBP
MAX BASS CONTROL
POWER
WIDE
SWEEP
MIN
MAX
MIN
MAX
35Hz
50Hz
80Hz
BALANCED
INPUT
DASH
REMOTE
OUTPUT
+12V - REM - GND
L R L R
DIGITAL BASS PROCESSOR
Remote Control
RTLDBP
POWER CONNECTION
• B+(12V) - Connect the red wire to the car battery or other power source.
• Remote - Connect the orange wire to the remote activating (12V DC) wire of the car stereo or
equalizer.
• GND - Connect the black wire to the car chassis for ground connection.
BlackRed
Orange
Battery
+ –
