MTX Road thunder - Signal Connection; Output Connections

MAX BASS CONTROL
POWER
WIDE
SWEEP
MIN
MAX
MIN
MAX
35Hz
50Hz
80Hz
BALANCED
INPUT
DASH
REMOTE
OUTPUT
+12V - REM - GND
L R L R
DIGITAL BASS PROCESSOR
Remote Control
RTLDBP
SIGNAL CONNECTION
For signal connection, the output RCA connectors should be connected to the next component after
the RTLDBP, such as a crossover, equalizer, or amplier.
Equalizer
Crossover
4Ω4Ω
4Ω
4Ω
4Ω
4Ω
4Ω
4Ω
4Ω4Ω
4Ω
4Ω
4Ω
4Ω
4Ω
4Ω
Subwoofer
Speakers
Amplier
Amplier
