MTX TERMINATOR Series - Specifications Overview; TN250.1; TN500.1; TN1000.1 Specs

11MTX.COM
SPECIFICATIONS
Model
TN250.1 TN500.1 TN1000.1
Circuit Topology Mono Class-D Mono Class-D Mono Class-D
RMS Power Output at 1Ω N/A N/A 1000W
RMS Power Output at 2Ω 250W 500W 700W
RMS Power Output at 4Ω 150W 300W 400W
RMS Power Output at 4Ω Bridged N/A N/A N/A
Total Harmonic Distortion <0.3% <0.3% <0.3%
Signal to Noise Ratio >95dB >95dB >95dB
Input Sensitivity 6V - 200mV 6V - 200mV 6V - 200mV
Crossover Range 50Hz - 250Hz 50Hz - 250Hz 50Hz - 250Hz
Frequency Response 20Hz - 250Hz 20Hz - 250Hz 20Hz - 250Hz
Bass Boost 0dB - 12dB 0dB - 12dB 0dB - 12dB
Subsonic Filter 10Hz - 55Hz 10Hz - 55Hz 10Hz - 55Hz
EBC Remote Knob Ye s Ye s Ye s
Recommended Fuse Rating 50A 80A 125A
