MTX TERMINATOR Series - TN150.2; TN300.4; TN800.5 Specs

12 MTX.COM
SPECIFICATIONS
Model
TN150.2 TN300.4 TN800.5
Circuit Topology Full Range Class-D Full Range Class-D Full Range Class-D
RMS Power Output at 1Ω N/A N/A N/A
RMS Power Output at 2Ω 75W x 2CH 75W x 4CH 75W x 4CH + 500W
RMS Power Output at 4Ω 50W x 2CH 50W x 4CH 50W x 4CH + 350W
RMS Power Output at 4Ω Bridged 150W x 1CH 150W x 2CH
150W x 2CH
(CH1/2/3/4)
Total Harmonic Distortion <0.3% <0.3% <0.3%
Signal to Noise Ratio >90dB >90dB >90dB
Input Sensitivity 6V - 200mV 6V - 200mV 6V - 200mV
Crossover Range 40Hz - 400Hz 40Hz - 400Hz
40Hz - 400Hz (CH1-4)
20Hz - 250Hz (Sub)
Frequency Response 20Hz - 20KHz 20Hz - 20KHz 20Hz - 20KHz
Bass Boost N/A N/A 0dB - 12dB (Sub)
Subsonic Filter N/A N/A N/A
EBC Remote Knob No No Ye s
Recommended Fuse Rating 30A 60A 125A
