MTX Thunder4202 - Amplifier Output Connections

ZiiW~Rf~E~4244
Amplifier Output Connections
Stereo Front
& Rear
Stereo Front
Minimum Wire Size:
I
-Ground To Metal Of Vehicle
Connect to Car Stereo
Remote/Power Antenna
Turn-On Wire
Disconnect 1
Battery Negative (4 Cable
Power: 8 AWG. Ground: 8 AWG.
Remove Pain+
from Metal
Prior td Installing Amplifier
For installation options go to www.mtxaudio.com
