Mueller U-700 - Overview of Machine Parts and Controls

• Do not open the handle when the machine is brewing.
• Always pull out the power plug before cleaning the machine
• Only use the machine in a dry room
Thoroughly rinse out the water tank with fresh water before using for the
accompanying the appliance.
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to
alert the user to the presence of uninsulated “dangerous voltage” within the product’s
to persons
6
OVERVIEW OF MACHINE PARTS AND CONTROLS
Brewer head handle
Brewer head
Water Outlet piecer
K-cup pack
K-cup pack housing
Water level indicator
Drip tray plate
Drip tray
Drip tray base
Reservoir lid
Reservoir
On/Off switch
Short size serving
Middle size serving
Long size serving
1
10
11
2
3
4
5
6
7
8
9
12
13
14
15
