Muirhead 3565 - Technical Specifications; Additional Specifications; Power Supply; Inputs

M0160.docx | Rev 1.3 | Last modified 19/05/2020 | © Remote Control Technologies Pty Ltd
23 | 28
Technical Specifications
⚠ Caution
Read prior to the installation of the product. Incorrect fitment will void the manufacturer’s warranty.
Dimensions, control unit only:
Length: 125 mm | Width: 40 mm | Height/Depth: 80 mm
Dimensions, boxed for freight:
Length: 140 mm | Width: 140 mm | Height/Depth: 70 mm
Weight, control unit only:
0.65 kg
Weight, including harness /
packaging for freight:
0.85 kg
Input nominal voltage:
12 to 24 V
Operating temperate range:
0 to 70 °C
Connection types:
12-pin Deutsch receptacle
Inputs:
Ignition, ground switches and sensors
Min & max input voltage:
8 to 32 Vdc
Circuit protection:
Reverse polarity protected outputs are current overload protected
Enclosure type:
Aluminium powder coated
Environmental protection IP rating:
IP65
Programming/adjustment:
Refer to document number P0021
Additional Specifications
Power Supply
Supply spike withstand
Absolute maximum spike (1J):
250 A (8/20 µs pulse)
− 1 event:
100 A / 50 µs, 8 A / 1 ms
− 10 events:
30 A / 50 µs, 4 A / 1 ms
− 100 events:
20 A / 50 µs, 3 A / 1 ms
− 1000 events:
15 A / 50 µs, 2.5 A / 1 ms
Inputs
Spiked supply voltage:
100 Vdc @ 200 ms | 200 Vdc @ 20 ms | 300 Vdc @ 2 ms
Outputs
Current rating:
Maximum 6 A continuously
Inrush current rating:
Maximum 30 A
Note
1. Outputs have protection incorporated to protect from installation error causing shorted outputs.
2. Outputs are current overload protected.
