Then tighten the preload nut until counterpressure is felt at the quick-release lever
from the middle of the entire lever travel and the force of the ball of the hand is
required at the end of the lever travel to close the lever completely. It must not
be possible to twist or tilt the saddle when the saddle clamp is closed. Align the
saddle so that it is in line with the top tube.
The foot is optimally positioned on the pedal when
the ball of the foot is above the pedal axle.
Make sure that you can still reach the ground with
the tips of your feet when sitting on the saddle.
The maximum load on the saddle is 100kg. This includes
backpack and other weights on the rider‘s body.
Consider all weights that you load in addition to their own
weight on the seat tube. The load limit of 100kg must not
be exceeded!
The quick-release must be rmly closed and t tightly
against the seat post before you start riding. The tip of the
lever must point forward when closed ( see also illustration
on page 29 below).
Adjusting the handlebar height
The e-muli has height-adjustable stem adapter,
through which the handlebar height can be adjusted in
height by up to 10cm with few simple steps.
Open the quick release lever on the handlebar stem
and pull the handlebars up as far as you need and then
close the quick release again.
Make sure you never adjust the stem adapter so that it is pulled
past the min/max mark and the quick release lever is rmly closed.
Adapting the e-muli to the rider
