Examples of load distribution:
Example 1: 80kg driver + 33kg tare weight e-muli
According to the maximum permissible total weight of 195kg, maximum of 82kg
may be loaded here. Of these 82kg may be loaded into the load basket
maximum of 70kg may be loaded. The remaining 12kg may be partially or com-
pletely loaded onto the seat post (e.g. in the form of backpack) or onto the
luggage carrier.
Example 2: 100kg rider + 33kg own weight e-muli
According to the maximum permissible total weight of 195kg, maximum of 62kg
may be loaded here. These 62kg may be loaded completely in the load basket or
distributed between the load basket and the luggage carrier, whereby the lugga-
ge carrier load may not exceed 18kg. On the seat post, however, no further load
may be applied here.
Note that the e-muli is not approved for the mounting of
child seats on the seat tube or even the seat post. The
attachment of such child seats can lead to deformation of
the frame.
Frame number/serial number
The frame number is stamped into the
frame and is located at the marked posi-
tion in the picture.
Permissible total weight
The permissible total weight of the e-muli is 195kg. This permissible maximum
weight may be further restricted under certain circumstances by the component
manufacturer‘s recommendation for use.
The permissible total weight is composed of:
Dead weight of the muli 25kg
+ weight of the driver
+ weight of the payload
Permissible maximum load limits of the various
load suspension points:
- Luggage carrier: Max 18kg
- Seatpost: Max 100kg + rider + backpack
- Cargo basket: Max 70kg
Max 18kg
Max 100kg
Max 70kg
Trailer
The muli is not approved for the use of trailers.
Note on the suspension seatpost:
The suspension seatpost in our program is equipped with spring for
maximum rider weight of 85kg. For higher rider weight you must resort to
non-suspended seatpost or retrot spring with higher permissible total weight.
