Adjusting the child seat
The knot in the rubber band allows the seat angle of the backrest to be adjusted
somewhat in the position against the direction of travel. Be aware that once the
knot is very tight, it is very dicult to loosen.
Make sure to select the appropria-
te harness height on the backrest
for your child. To adjust the harness
height, turn the harness end piece
on the back of the seat and slide
it forward through the slotted hole.
Then select the desired height and
push the end piece through the slot
again from the front.
The rods from which the child seat
is suspended can be adjusted in
width. The end pieces can be turned
out and in when the lock ring is loo-
sened. The rods are adjusted from
the factory so that some pressure
is needed on the wings to insert the
rods. This is important so that the
rods are locked well into the basket.
So, do not adjust the rods so that
they are very loose in the basket.
Insert both rods parallel and uniformly into the prole angles
on the right and left. Always remove the rods from the prole
angles in parallel. If one end of the rod is inserted and remo-
ved on one side at rst, it can tilt very easily and the seat
cannot be installed properly.
If you insert or remove the rods from one side, large lever-
age force is created which can quickly cause you to damage,
bend or break the rods and the prole angles.
Due to the hanging system and the seat belts, the children in
the seat are very well protected from road impacts. Never-
theless, you should always drive carefully and with foresight
when transporting children in the e-muli and avoid strong
road impacts and abrupt braking.
Child seat and child transport in the e-muli
