Safety symbols
On various places on the Multi-Mover XL35 you will find standardized safety symbol stickers
as displayed to the right.
The upper part warns against a general or particular hazard.
The lower part indicates what type of hazard is being warned against and will explain what
you must do.
2 TECHNICAL DESCRIPTION
2.1 Designation, identification and description
Designation : MULTI-MOVER XL35
Identification : type plate on the encasing
Description : vehicle on two drive wheels and a swivel wheel
: suitable as towing device, optionally provided with an upward and downward mov-
ing coupling point, for instance, in order to couple the pole of a trailer and possibly to
lift it.
: drive while walking, by using the driving switches on the steering handle
Accessories
The following parts are delivered separately with the vehicle:
The vehicle's operation manual
Acid weighing unit (optional)
Battery loading report booklet (optional)
Manuals for possible options
2.2 Technical information and dimensions ( # = optional different)
- Weight 150-380 kg
- Length 165 cm
- Width 70 or 80 cm
- Height 103 cm
- Engine power 800 watts 24VDC 130A, maintenance-free
- 2 x 12-volt 55 Ah batteries, maintenance-free, AGM lead acid #
- External high-frequency charger 24 volts 8A #
- Push and Pull 3,500 kg, 2,000 newton horizontal traction
- Air tyres with block profile 15 cm wide x 6.00, 6-inch rims. #
- Solid-rubber swivel castor, ∅ 200 mm #
- Ergonomic tiller head with emergency stop, belly button
- Potentiometer for continuously adjustable maximum speed to 5 km/h
- Tiller head can fold together #
- Gross axle weight 380 kg #
- Battery display
- Lock with 2 keys #
- Minimum speed is 0.3 km/h
- Emergency stop switch on the housing
- Horn
- Tow bar coupling to 45 cm height, in height adjustable #
