2 TECHNICAL DESCRIPTION
2.1 Designation, identification and description
Designation : MULTI-MOVER XL50
Identification : type plate on the encasing
Description : vehicle on two drive wheels and a swivel wheel
: suitable as towing device, optionally provided with an upward and downward moving
coupling point, for instance, in order to couple the pole of a trailer and possibly to lift it.
: drive while walking, by using the driving switches on the steering handle
Accessories
The following parts are delivered separately with the vehicle:
The vehicle's operation manual
Manuals for possible options
2.2 Technical information and dimensions # = Optionally different
___________________________________________________________________________
Maximum traction load kg 5000
Maximum traction force N 2250
Length x width x height mm 1600 x 820 x 970
#Weight, batteries excl. kg 160 (with batteries 190)
#Speed, empty km/h 0 - 5
#Maximum slope angle, with /
without load % 4 / 12
Wheels, driven, standard - 15 x 6.00 – 6 4 ply
#Tyre pressure bar 2.1
#Wheels, solid - 4.00/8 rim size 3.000
Brake, hand electromagnetic - tie rod
Motor Watt 1500 24Volt
#Battery Amps/hour 55/20h
l x w x h mm 165 x 135 x 65
Battery charger, min. Amps 24V/ 8A (HF charger + automatic stop)
Optionally different(#)
2.3 Packaging, loading / unloading, towing, recycling
Packaging
The Multi-Mover XL50 is secured with straps on support beams on a pallet, surrounded by a protective
cardboard box.
Removing the packaging
Remove the clamping strips at the wheels.
Avoid injury and damage as a result of incorrect placement of the lift truck's lift forks.
Loading and unloading
If the Multi-Mover XL50 has to be moved by means of a lift truck, the lift forks must be placed at the
heaviest part at the rear of the Multi-Mover XL50, between the 2 large wheels.
Towing
Caution! Avoid serious damage to the drive, the Multi-Mover XL50 may only be moved or towed if the
hand brake tie rod (round black button) on the dashboard has been pulled out.
Recycling of the packaging
Save the packaging for possible future transportations.
If you want to remove the packaging, you must observe the local and national regulations concerning
plastic waste processing.
