Characteristics
Description
Sweep speed range
(S/div)
5ns/div - 1000s/div,
Stepping in the 1-2-5 way
Time base accuracy
±100 ppm
Record length
Single channel: up to 8K
Dual channel: 4K
Vertical
Sensitivity
(Volt/div) range
10 mV/div～10 V/div
Displacement range
±6 div
Analog bandwidth
MP720781;MP720780
40 MHz
MP720783;MP720782
70 MHz
Single bandwidth
Full bandwidth
Low frequency
response
(AC coupling, -3dB)
≥10 Hz
Rise time
(typical on BNC)
MP720781;MP720780
≤ 8 ns
MP720783;MP720782
≤ 5 ns
DC gain accuracy
3%
Measurement
Cursor
ΔV, ΔT, ΔT&ΔV between
Automatic
Period, Frequency, Mean, PK-PK,
Max, Min, Amplitude
Trigging
Source
CH1, CH2
Type
Edge
Coupling
DC, AC
Trigger type
Auto, normal, single
Trigger electrical
level range
±4 divs from the center of the screen
Trigger electrical
level accuracy
±0.3 div
Trigger
displacement
According to Record length and time base
Edge
trigging
Slope
Rising edge, falling edge
