User Manual
27
Multi-device View
Function
(Details follow)
Range
AUTO/MANUAL
Slide up/down to
show other device
Slide left to show the
Delete softkey
Function Description Table
Display
Function
Display
Function
DC
Direct Current
CAP
Measuring Capacitance
AC
Alternating Current
Hz
Measuring Frequency
RES
Measuring Resistance
DUT
Measuring Duty Cycle
DIO
Testing Diodes
TEMP
Measuring Temperature
BEEP
Testing for Continuity
NCV
Non-contact Voltage Detect
Graph&Table View
Show/hide the table
Select device
Zoom the graph using
button or gesture
Record/pause
Save the displayed data into .CSV file
Clear the data that is being displayed
Enter the selecting file interface
Enter the setting Interface
