Multifan 130 - Assembly; Assembly Requirements

Galvanized Box Fan 130
4 | ENGLISH Original instructions INS00025-A
4 Assembly
This product is supplied either assembled or unassembled depending on how
it was ordered.
NOTICE
Assembly must be carried out by skilled persons
Before commencing assembly, check that nothing has been damaged during
transport.
When this product is supplied unassembled, the assembly instructions are
supplied separately and are part of these instructions.
CAUTION
Some parts may have sharp edges
Risk of cuts
5 Information
5.1 Overview
1 Intake guard
2 Motor and motor rating plate
3 Fan housing
4 Impeller
5 Shutter
The number and type of fan blades in the impeller in your fan may vary from
illustrations shown in this document.
10NR-3 12BR-3 12BR-6
Illustration1: Possible impeller models used in this fan series
5.2 Options
This Galvanized Box Fan 130 can be delivered with one of more of the
following options. The assembly instructions of the options are supplied
separately and are part of these instructions.
Illustration2: Wall mounting set
Illustration3: Cone
Illustration4: Wire guard on the air outlet
