6. Specifications
6. Specifications
6.1 FM
Tuning range FM tuning interval:
100 kHz
switchable
87.5 – 107.9 MHz
Aerial terminal External aerial connector
Intermediate frequency 10.7 MHz
Usable sensitivity 11 dBf
Selectivity 75 dB at 400 kHz
Signal-to-noise ratio 65 dB (stereo)
68 dB (mono)
Harmonic distortion at 1 kH 0.7 % (stereo),
0.5 % (mono)
Separation 33 dB at 1 kHz
Frequency response 30 – 15,000 Hz
6.2 Power amplifier section
Outputs Speaker outputs
(sure seal connectors)
Speaker impedance 4 – 8 ohms
Maximum power output 4 outputs at 12,5 W
6.3 General
Outputs Audio outputs
Power aerial relay controllead
