Section 2 Installation
Part Number 000003912 6/17 2-5
KITCHEN EQUIPMENT INSTALLER
REPRESENTATIVE RESPONSIBILITIES
Prior to scheduling Multiplex Equipment installer,
the following steps listed below must be completed:
1. Usable floor sewer drain.
2. A 120 VAC, 3-wire, 1 Phase, 60 Hz Electrical Power
Supply (minimum 30 Amp capacity).
- Model 44 is 208/230, 3-wire, 1 Ph 60 Hz
- Model 50 is 208/230, 4-wire, 3Ph 60 Hz
- International Models are 50 Hz
3. Usable potable water.
4. CO
2
Gas (bulk or bottled supply); minimum 3/8" line.
5. One 5 gallon (19 L) container or Bag-In-Box
container of each post mix syrup flavor.
6. A 120 VAC, 3-wire, 1 Phase, 60 Hz dual wall
receptacle for optional electrical equipment
(domestic only).
NOTE: Do not schedule the authorized Multiplex
Equipment Installer until all of the above have been
completed. It will only result in charge-backs to you for
the unnecessary trips.
REQUIREMENTS FOR POST MIX REFRIGERATION
UNITS
• Conduit can be run through floor or ceiling chase.
• 60°F (15.6°C) minimum and 105°F (40.5°C)
maximum operating ambient conditions.
• For indoor installation only.
• Syrup supply can be located on stand or adjacent to
refrigeration unit.
Installer Instructions
These equipment instructions are intended to assist
qualified personnel in the unpacking, locating and the
initial operation of the Multiplex Beverage Equipment
Post Mix Refrigeration Unit.
PREPARATION
The Multiplex Beverage Equipment Post Mix
Refrigeration Unit is pre-assembled in the factory and
requires minimum installation.
For future reference or to be used when ordering parts,
record the Model Number, Serial Number, Part Numbers
of Unit, Condenser (if remote), Towers, etc., and Date of
Installation on the inside of this Manual. Leave manual
on site in a safe place. Do not discard manual.
Ambient Location Requirement
This equipment is rated for indoor use only. It will not
operate in sub-freezing temperature. In a situation when
temperatures drop below freezing, the equipment must
be turned off immediately and properly winterized.
Contact the manufacturer for winterization process.
Carbon Dioxide (CO
2
) displaces oxygen. Exposure
to a high concentration of CO
2
gas causes tremors,
which are followed rapidly by loss of consciousness
and suffocation. If a CO
2
gas leak is suspected,
particularly in a small area, immediately ventilate the
area before repairing the leak. CO
2
lines and pumps
must not be installed in an enclosed space. An
enclosed space can be a cooler or small room or
closet. This may include convenience stores with
glass door self serve coolers. If you suspect CO
2
may build up in an area, venting of the BIB pumps
and/or CO
2
monitors must be utilized.
The remainder of these instructions is to be
completed by an authorized Multiplex Installer.
This publication must be saved for future reference.
Read instructions before attempting installation.
