Multiplex AcroMaster Pro User Manual

8
Accessories and tools
Wingspan: 1100 mm
Overall length: 1150 mm
Flight weight: Approx. 1350 g
Wing area: 36.6 dm²
Wing loading: 36.9 g/dm²
RC functions: Aileron, elevator, motor, rudder
Specications
Required accessories Optional accessories
• WINGSTABI 7-channel # 5 5010
• WINGSTABI RX-7-DR M-LINK # 5 5012
• Receiver RX-7-DR M-LINK 2.4 GHz # 5 5811
• Multiplex G sensor for M-LINK # 8 5409
• Propeller balancer # 33 2355
• Decal sheet blue-red # 1-00856
• Decal sheet yellow-silver # 1-01012
• Activator spray for CA adhesive
• Medium-sized cross-tip screwdriver
• Hex wrench 1.5
• 10 mm open-ended wrench or socket wrench
• 220-320 grit sandpaper
Scope of delivery AcroMaster PRO RR
• ELAPOR
®
model (almost fully assembled)
• Drive motor Roxxy BL C35-48-990kv
• Controller Roxxy BL Control 755 S-BEC
• 12x6“ propeller
• 2 servos HS-82 MG
• 2 servos HS-65 HB
• 1x Zacki Elapor
®
20 g # 85 2727
• 1x receiver RX-5 light M-LINK 2.4 GHz # 55 808
• 1x battery ROXXY EVO LiPo 3 - 2600M 40C # 316656
The following tools are required to assemble the model:
List of parts AcroMaster PRO
Part No. Qty. Name Material Dimensions
1 1 Assembly instructions Paper DIN A4
2 1 Complaints form for models Paper DIN A4
3 1 ROXXY BL-Control 755 S-BEC instructions Paper DIN A4
4 1 Fuselage fully assembled Elapor Finished component
5 1 Left wing fully assembled Elapor Finished component
6 2 Right wing fully assembled Elapor Finished component
7 1 Elevator fully assembled Elapor Finished component
8 1 Canopy fully assembled / painted Elapor Finished component
9 1 Rudder fully assembled Elapor Finished component
10 1 Holder for spinner Plastic Finished component
11 1 Spinner EPP Ø 62 mm
12 1 Main spar CFRP Ø 10x620 mm
13 1 Auxiliary spar CFRP Ø 10x200 mm
14 1 Wing lock Wood Finished component
15 1 Battery board Wood Finished component
16 1 Undercarriage fully assembled Aluminum / Plastic Finished component
17 2 Self-tapping screws Steel, galvanized Ø 2.9x16 mm
18 1 Propeller Fiber-reinforced plastic Ø 12x6"
19 1 Propeller coupling Aluminum Ø 5/6 mm
20 3 Mushroom head hook and loop tape Plastic 25x60 mm
21 3 Velour hook and loop tape Plastic 25x60 mm
22 2 Hook and loop strap Plastic Finished component
EN

Multiplex AcroMaster Pro Specifications

General

Type	Aircraft model
Purpose	Utility aircraft
Material	Plastic
Product type	Fixed-wing aircraft model
Certification	CE
Compatibility	Acromaster Pro
Movable parts	Yes
Product color	Blue, Red
Construction type	Preassembled
Original model name	AcroMaster PRO

Weight and Dimensions

Length	1150 mm
Weight	1350 g
Wingspan	1100 mm
