Multiplex Albi 4 14-2003-05 User Manual

34
Section 3
CHASSIS EARTH (REAR PANEL)
GN/YLW
SYRUP PUMP 4
SYRUP PUMP 3
SYRUP PUMP 2
SYRUP PUMP 1
THERMISTOR - BATH (OPTIONAL)
THERMISTOR - AMBIENT (OPTIONAL)
THERMISTOR - FRIDGE (OPTIONAL)
24VDC
STILL DISPENSE SOLENOID
SODA DISPENSE SOLENOID
24VDC
DISPLAY
CARB FILL STOP SOLENOID (STILL DRINK OPERATION)
FLOOD PROTECTION SOLENOID
CARB BOWL LEVEL CONTROL
BLACK
GN/YL
WHITE
ICE BANK PROBE
L N
L
N
L N E
L
N
E
L
N
E
L
N
E
CARBONATOR PUMP MOTOR
BLUE
BLUE
GN/YLW
BLUE
COMPRESSOR
FAN MOTORS
BLUE
MAINS SUPPLY 115/230VAC FILTER IEC SOCKET
AG.
RED
BLACK
BLUE
BROWN
BROWN
BLUE
GN/YL
RED
RED
CO2 PRESSURE SWITCH (OPTIONAL)
24VDC INPUT FROM P.S.U.
115/230VAC OUTPUT TO P.S.U.
BROWN
BROWN
BROWN
BROWN
BROWN
BLUE
GREEN / YELLOW
AGITATOR MOTOR
1
2
3
4
CHASSIS EARTH
(REAR PANEL)
CHASSIS EARTH (REAR PANEL)
ALBI & ALBI AQUA DISPENSER WIRING DIAGRAM
NOTES: 1. THE PRINTED CIRCUIT BOARD IS CAPABLE OF OPERATION AT 115VAC
OR 220-240VAC
2. THE ALBI COOLER IS AVAILABLE IN 115VAC AND 220-240VAC VERSIONS
NOTE: ALBI Aqua units are not tted with Syrup pumps.
