Multiplex Hyper Warwick R290 User Manual

33
Section 6
Section 6 – Wiring Schematic
01-3000-xx Hyper Warwick Integral
BLACK
BLUE
GN/YLW
RED
1.50mm2 BLACK TRI CORE CABLE 2.5M TOTAL LENGTH
MOULDED PLUG 13 AMP FUSE
BROWN
BLACK
BLUE
BROWN
BLUE
BROWN
BLUE
GRN/YLW
BROWN
BLUE
GRN/YLW
AGITATOR MOTOR CONNECTION
COMPRESSOR NEUTRAL
DFX SERIES 1E CONTROLLER
SW LIVE
LIVE 2
LIVE NEUTRAL
PROBE 1
PROBE 2
PROBE
GREEN NEON
SLIDER SWITCH
RED NEON
IEC SOCKET CARBONATOR POWER
BROWN
BLUE
GRN/YLW
COMPRESSOR LIVE
COMPRESSOR EARTH
HYPER WARWICK R290 WIRING SCHEMATIC (INTEGRAL)
FAN NEUTRAL
FAN LIVE
FAN EARTH
BLUE
BROWN
GN/YLW
CONDENSER FAN
COMPRESSOR
SODA RE-CIRC PUMP
BROWN
BLUE
PUMP LIVE
PUMP NEUTRAL
GRN/YLW
PUMP EARTH
RED
BROWN
BLUE
