8
Additional items required:
RC system components: Function
MULTIPLEX Micro 5/7 receiver Order No. 5 5933
MULTIPLEX MS-X2 servo (2 required) Elevator / aileron Order No. 6 5040
PiCO-Control 400 Speed control Order No. 7 2250
Pushrod connector Order No. 70 3454
Alternatively:
PiCO “Ein-Stein” (module containing Elevator / aileron Order No. 1 4004
2 servos, receiver, switch)
PiCO Control 400 Speed control Order No. 7 2250
Pushrod connector Order No. 70 3455
Flight battery:
MULTIPLEX 7/500 AR flight battery Order No. 15 5648
Battery charger:
PiCO AUTO-charger for rapid-charging transmitter and flight packs Order No. 9 2526
Adhesive:
MULTIPLEX 100 g (5-minute epoxy) Order No. 60 3848
Tools:
Scissors, combination pliers, balsa knife, razor saw or hacksaw blade, screwdriver.
Specification:
Wingspan 895 mm
Fuselage length 515 mm
All-up weight RC electro approx. 530 g
RC glider approx. 330 g
Wing loading approx. 19.5 dm²
Wing loading approx. 27 / 17 g/dm²
RC functions Aileron, elevator and motor
Caution!
Radio-controlled models, and especially model aircraft, are by no means playthings. Building and
operating them safely requires a certain level of technical competence and manual skill, together with
discipline and a responsible attitude at the flying field. Errors and carelessness in building and flying
the model can result in serious personal injury and damage to property. Since we, as manufacturers,
have no control over the construction, maintenance and operation of our products, we are obliged to
take this opportunity to point out these hazards, and to emphasise your personal responsibility.
Building instructions
Order No. 21 4085
1. Examine your kit carefully!
MULTIPLEX model kits are subject to constant quality checks throughout the production process, and we sincerely
hope that you are happy with the contents of your kit. However, we would ask you to check all the parts before you
start construction, as we cannot exchange components which you have already worked on. If you find any part
is not acceptable for any reason, we will readily correct or exchange it. Just send the component to our Model
Department. Please be sure to include a brief description of the fault.
We are constantly working on improving our models, and for this reason we must reserve the right to change the kit
contents in terms of shape or dimensions of parts, technology, materials and fittings, without prior notification.
Please understand that we cannot entertain claims against us if the kit contents do not agree in every respect with
the instructions and the illustrations.
