MC94P/S CONCRETE MIXERS — OPERATION AND PARTS MANUAL — REV. #9 (09/15/11) — PAGE 37
MC94P/S — PLASTIC BARREL
PLASTIC BARREL ASSY.
NO PART NO PART NAME QTY. REMARK
1 514061 RING GEAR 1
2 EM969013 NUT, LOCK 3/8” NC 4
3 508492 BARREL, PLASTIC 9 CU. FT. 1
4 505390 PLUG, EXPANSION 1
5 508491 KING PIN 1
6 510955 SPINDLE BEARING CONE 2
7 510956 SPINDLE BEARING CUP 2
8 514930 SUPPORT SPIDER 1
9 511758 SHIM PLASTIC #14 AR
10 511759 SHIM PLASTIC #16 AR
11 EM963057 BOLT 3/8" NC 1-1/2" G5 4
12 492378 BOLT 3/8" NC 1-3/4" G5 16
13 507542 SUPPORT BRACKET, UPPER 4
14 492598 WASHER, FLAT 16
15 492583 NUT, HEX 3/8" NC 16
16 508497 PLASTIC BLADE, VERT. LONG 2
16A 508498 PLASTIC BLADE, VERT. SHORT 2
17 507541 SUPPORT BRACKET, LOWER 4
19 507538C SPACER MC8079 4
20 508345 BOLT, FLAT HEAD 3/8" NC X 3-1/2" G 4
21 EM926036 RING, RETENTION 2
22 514515 DRIVE PINION SHAFT 1
23 492179 BEARING, PINION SHAFT 2
24 EM963692 BOLT 1/2" NC X 1-1/2" G5 2
25 502036 HOUSING, JACKSHAFT 1
26 492584 LOCKNUT, HEX 1/2" NC 2
27 491008 CAP, GREASE FITTING 3
28 EM916001 GREASE FITTING 1/8" NPT 3
29 500246 SQUARE KEY 1/4 X 35 MM 1
30 503915 DRIVE PINION 1
31 492468 ALLEN SCREW 5/16 NC 1/2" 1
32 492491 SET SCREW 1/2" X 1" NC 1
33 07037-024 NUT, HEX LOWER 1-1/2" NF ................. 1 .............. REPLACES EM968306
34 505079 BOLT 5/8" NC X 1-1/4" NC 1
35 492586 LOCKNUT, HEX 5/8" NC 1
36 510647 YOKE 1
37 508496 BLADE, PLASTIC (SHOVEL) 2
38 500980 WASHER, FLAT 1-9/16" 1
39 505472 SPACER, BARREL 1
40 515450 STEEL BLADES .................................... 3 ............... EFFECTIVE 02/2005
