MULTIQUIP MC94PH8 - Control Assembly

MC94P/S CONCRETE MIXERS — OPERATION AND PARTS MANUAL — REV. #9 (09/15/11) — PAGE 57
HONDA GX240K1QA2 ENGINE — CONTROL ASSY.
CONTROL ASSY.
NO. PART NO. PART NAME QTY. REMARKS
2 16551ZE2000 ARM, GOVERNOR 1
3 16555ZE2000 ROD, GOVERNOR 1
4 16561ZE2000 SPRING, GOVERNOR 1
5 16562ZE2000 SPRING, THROTTLE RETURN 1
8 16570ZE2W20 CONTROL ASSEMBLY ................................ 1 .......... INCLUDES ITEMS W/
*
10
*
16571ZE2W00 LEVER, CONTROL 1
11
*
16574ZE1000 SPRING, LEVER 1
12
*
16575ZE2W00 WASHER, CONTROL LEVER 1
13 16576891000 HOLDER, CABLE
14
*
16578ZE1000 SPACER, CONTROL LEVER 1
15
*
16581ZE2W00 BASE, CONTROL 1
16
*
16584883300 SPRING, CONTROL ADJUSTING 1
17 16592883310 SPRING, CABLE RETURN 1
19 90013883000 BOLT, FLANGE (6 X 12) (CT200) 2
20 90015ZE5010 BOLT, GOVERNOR ARM 1
21
*
90114SA0000 NUT, SELF- LOCK (6MM) 1
24
*
93500050280A SCREW, PAN (5 X 28) 1
26 93500050160A SCREW, PAN (5 X 16) 1
27 9405006000 NUT, FLANGE 1
