MC94P/S CONCRETE MIXERS — OPERATION AND PARTS MANUAL — REV. #9 (09/15/11) — PAGE 39
MC94P/S — STEEL BARREL
STEEL BARREL ASSY.
NO PART NO PART NAME QTY. REMARK
1 505390 PLUG, EXPANSION 1
2 505469 KING PIN 1
3 510955 SPINDLE BEARING CONE 2
4 510956 SPINDLE BEARING CUP 2
5 514061 RING GEAR 1
6 EM9633057 BOLT 3/8" NC 1-1/2" G5 6
7 505473 BARREL, STEEL 9 CU. FT. 1
8 511732 SHIM 0.25 THICK AR
8 511729 SHIM .100 THICK AR
8 511730 SHIM .140 THICK AR
8 511731 SHIM .187 THICK AR
9 EM969013 NUT, LOCK 3/8” NC 6
10 490962 SNAP RING 2
11 514515 DRIVE PINION SHAFT 1
12 492179 BEARING, PINION SHAFT 2
13 EM963692 BOLT 1/2" NC X 1-1/2" G5 2
14 492584 LOCKNUT, HEX 1/2" NC 2
15 502036 HOUSING, JACKSHAFT 1
16 491008 CAP, GREASE FITTING 3
17 EM916001 GREASE FITTING 1/8" NPT 3
18 500214 SQUARE KEY 1/4" X 30 MM 1
19 503915 DRIVE PINION 1
20 492467 ALLEN SCREW 5/16 NC 3/8" 1
21 EM505472 SPACER, BARREL 1
22 492491 SET SCREW 1/2" X 1" NC 1
23 07037-024 NUT, HEX LOWER 1-1/2" NF ................... 1 ............. REPLACES EM968306
24 492406 BOLT 5/8" NC X 1-1/2" NC 1
25 492586 LOCKNUT, HEX 5/8" NC 1
26 510593 YOKE 1
