MC94P/S CONCRETE MIXERS — OPERATION AND PARTS MANUAL — REV. #9 (09/15/11) — PAGE 41
MC94P/S — MAIN FRAME ASSEMBLY
MAIN FRAME ASSY.
NO PART NO PART NAME QTY. REMARK
1 514245 GUARD, GEAR WHEEL 1
2 492621 WASHER, LOCK 1/4" 4
3 492278 ROUND HEAD BOLT 1/4" NC 3/8 G2" 4
4 514692 DUMP GEAR 1
5 492584 NUT, LOCK 1/2" NC 1
6 490895 DUMP LATCH 1
7 492395 BOLT 1/2" NC X 1-3/4" G5 1
8 EM916001 GREASE FITTING 1/8" NPT 2
9 491008 GREASE CAP 2
10 EM963055 BOLT 3/8" NC X 3/4" G5 3
11 3109092 WASHER, FLAT 3/8" 3
12 0166 A WASHER, LOCK 3/8" 3
13 514521 FRAME 1
14 10176 LOCK NUT 1/2 NC 1
15 EM124 BOLT 1/2"-13 X 4 G5 1
16 514723 HANDWHEEL SHAFT 1
17 501808 HANDWHEEL ............................................... 1 ............. REPLACES P/N 514002
18
*
SAFETY CHAIN 1
19
*
01004 CONNECTOR LINK ...................................... 2 ............. BEFORE JANUARY 2006
19
*
01004 CONNECTOR LINK ...................................... 1 ............. AFTER JANUARY 2006
19A
*
516580 CLEVIS SAFETY HOOK, 1/4" ..................... 1 ............. AFTER JANUARY 2006
20 490961 SNAP RING 1
21 13363KIT CHAIN AND LINK KIT .................................. 1 ............. INCLUDES ITEMS W/
*
22 HBC-1 BALL HITCH 2-INCH .................................... 1 ............. CONTACT UNIT SALES
23 HLC-1 LOOP HITCH ................................................ 1 ............. CONTACT UNIT SALES
24 HPC-1 PIN HITCH 1-INCH ....................................... 1 ............. CONTACT UNIT SALES
