MC94P/S CONCRETE MIXERS — OPERATION AND PARTS MANUAL — REV. #9 (09/15/11) — PAGE 43
MC94P/S — AXLE ASSEMBLY
AXLE ASSY.
NO PART NO PART NAME QTY. REMARK
1 492397 BOLT 1/2" NC 2-1/2" G5 4
2 EM969023 LOCK NUT 5/8" NC 4
3 501030 SPRING SUPPORT 2
4 4922406 BOLT 5/8" NC 1-1/2" G5 4
5 492589 NUT 1/2" NF 4
6 491928 SPRING LEAF 2
7 492584 NUT, HEX 1/2" 4
8 514545 AXLE 1
9 500617 U-CLAMP 2
10# EM914288 OIL SEAL 2
11# EM903113 BEARING CONE, 4
12# EM903012 BEARING CUP 4
13 EM941306 HUB ASSY., 4-BOLT ....................................................... 2 ........... INCLUDES ITEMS W/#
14 511159 WASHER, FLAT, .087" THICKNESS 2
15 501299 WASHER, FLAT, .135" THICKNESS AR
16 491688 COTTER PIN 1/8" X 1-1/2' 2
17 8164 NUT, SLOTTED HEX JAM 1"-20 2
18 3005 TIRE AND RIM, CARLISE 2
19# 8115 LUG NUTS 8
20# 3469 DUST CAP 2
