MC94P/S CONCRETE MIXERS — OPERATION AND PARTS MANUAL — REV. #9 (09/15/11) — PAGE 45
MC94P/S — CABINET ASSEMBLY
CABINET ASSY.
NO PART NO PART NAME QTY. REMARKS
1 490202 RUBBER PROTECTOR 4
2 514694 CABINET ENGINE ASSY. W/DECALS ....................1 ............. INCLUDES ITEM W/
*
3 492375 BOLT 3/8" NC X 1" G5 6
4 EM923023 WASHER, FLAT 5/16" 8
5 13287 LOCK NUT 8-32 ........................................................ 6 ............. REPLACEMENT PART ONLY
6 2203 WASHER, FLAT #10 ................................................. 6 ............. REPLACEMENT PART ONLY
7 1307 RHMS 8-32 X 1/2" ..................................................... 6 ............. REPLACEMENT PART ONLY
8
*
491010 LATCH ASSY., COMPLETE 2
9 492598 WASHER, FLAT 3/8" 12
10 2105164 NUT 3/8" NC G5 6
11 EM974007 PAINT, SPRAY CAN 12 OZ. TRAFFIC RED AR
To Next Page
