MC94P/S CONCRETE MIXERS — OPERATION AND PARTS MANUAL — REV. #9 (09/15/11) — PAGE 63
HONDA GX240K1QA2 ENGINE — CYLINDER BARREL ASSY.
CYLINDER BARREL ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 12000ZE2834 CYLINDER ASSY., BALANCER + OIL ALERT ...... 1 .......... INCLUDES ITEMS W/
*
2 15510ZE2043 SWITCH ASSY., OIL LEVEL 1
3 16541ZE2010 SHAFT, GOVERNOR ARM 1
6 90131896650 BOLT, DRAIN PLUG 2
7 90446KE1000 WASHER 8.2 X17X0.8 1
8
*
91201890003 OIL SEAL 30X46X8 1
9 91353671003 O-RING 14MM ARAI 1
10 9405010000 NUT FLANGE 10MM 1
11 031112230 WASHER, DRAIN PLUG 12MM 2
12 9425110000 PIN, LOCK 10MM 1
13 957010601200 BOLT, FLANGE 6X12 2
14
*
961006202000 BEARING, RADIAL BALL 6202 1
15 90013883000 BOLT, FLANGE 6X12 CT200 1
16 34150ZH7003 ALERT UNIT, OIL 1
