MC94P/S CONCRETE MIXERS — OPERATION AND PARTS MANUAL — REV. #9 (09/15/11) — PAGE 71
HONDA GX240K1QA2 ENGINE — MUFFLER ASSY.
MUFFLER ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 18310ZE2W00 MUFFLER 1
2 18320ZE2W01 PROTECTOR, MUFFLER 1
3 18323ZE2W00 PROTECTOR, EX. PIPE 1
4 18330ZE2W00 PIPE, EX. 1
5 18331ZE2810 CAP, MUFFLER 1
6 18333ZK6Y00 GASKET, EX. PIPE 1
7 18355ZE2010 ARRESTER, SPARK 1
8 18381ZE2W10 GASKET, MUFFLER (ARRESTER) 1
9 18381ZE2800 GASKET, MUFFLER 1
10 90013883000 BOLT, FLANGE (6 X 12) (CT200) 1
11 90050ZE1000 SCREW, TAPPING (5 X 8) 6
12 90055ZE1000 SCREW, TAPPING (4 X 6) 3
13 90050ZE1000 SCREW, TAPPING (5 X 8) (OPTIONAL) 1
14 9405008000 NUT, FLANGE (8MM) 5
