MULTISPAN CC-12 - Page 2

Basic Configuration
S E T
H Y
S T D T
D E L Y
C T
0 0 0. 0
0 5. 0
0 0 0
0 1 0
0 0 0 5
L - a L
Set
Power ON
(Set Value: 0.0 to CT Primary Value)
(Hys Value: 00.1 to 99.0)
(Staring Delay Time Value
: 000 to 999 SEC.)
Starting Delay time
Delay time
Delay time value 000 to 999
Hysteresis
CT Primary
Alarm select mode
(CT Primary Value: 5 to 1600 AC AMP)
Selected Alarm
Page - 2
www.multispanindia.com
Press & key to set setpoint value
Press & key to set Hystersis value
Press & key to set starting delay time
Press & key to set delay time value
Press & key to set CT Primary Value
Press & key to set High Alarm/Low Alarm
Press key to save & exit
Press key
Press key
Press key
Press key
Press key
Press key
CC-12
C R F C
0 0 0. 0
Correction Factor
(CF Range: -25.0 to +25.0)
Press & key to set correction factor value
Press key for to save & exit
Press & key together for 10 sec.
CORRECTION FACTOR
Key Operation
ENT
SET
2) Press & Key to change value or to select option.
3) Press Key to save changes in setting.
1) Press key to enter in menu.
