Page-9
MS-1248-M1
Mechanical Installation
MODEL
DIMENSIONS
A
96mm 96mm
92mm
92mm 3mm 53mm 56mm
B
C
D E
F G
G
B
C
Top View
F
D
E
Right Side View
A
B
MS 1248-M1
